Our capsule polisher stands out through its precise output-side quality control that ensures maximum process efficiency, combined with minimized downtime thanks to the included extra brush and fast changeover design. The unit offers exceptional production adaptability with both standard and sorting model options to meet varying operational needs. Fully GMP compliant and meeting all FDA requirements, it delivers long-term reliability through industrial-grade components engineered for continuous 24/7 operation.

Features

  • Empty cap eliminator mounted on the output side for reliable defective capsule ejection;

  • Includes 1 extra brush with each unit for immediate replacement, Quick-release design for brush changes in seconds;

  • Dual model options: a standard version for high-efficiency polishing, or a sorting model that adds automatic rejection of underweight, broken, and empty capsules.

  • Non-contact design protects printed capsule surfaces;

  • Cyclonic airflow ensures zero powder residue;

  • Heavy-duty stainless steel construction, Hermetically sealed components;

  • Single-phase motor with frequency converter

Specification

Model:JFP-2YJP-C
Maximum capacity420000 capsules/hr150000 capsules/hr
Power Supply110V/60Hz220V,50Hz,2A,Single-phase
Power180W150W
Compressed air pressure<0.4mPa-
Compressed air flow>270 L/min-
Vacuum>1000L/min, >0.13mbr>1000L/min, >0.13mbr
Noise:<75 DB (A)<75 DB (A)
Dimensions:1000*600*960mm800*550*1000mm
Weight:43 Kg40 Kg

Product video

Horizontal Sorting Capsule Polishing Machine

FAQ

  • Q: What is Capsule Polishing and Sorting Machine?

    A Capsule Polishing and Sorting Machine is a pharmaceutical equipment used to remove dust and imperfections from filled capsules while automatically detecting and rejecting defective ones (such as underweight, broken, or empty capsules) to ensure final product quality and compliance. It combines mechanical polishing with advanced sorting technology to streamline capsule finishing processes in production lines.

  • Q: How does a capsule polishing machine work?

    A capsule polisher cleans capsules through gentle brushing and airflow in a polishing chamber. It uses compressed air to remove dust without damaging capsules. Advanced models automatically detect and eject defective capsules using optical or weight sensors.

  • Q: What are the functions of a vertical polishing machine?

    A:The machine polishes the powder on the capsules by conveying the material from the bottom to the top, ensuring a more thorough and cleaner polishing process. It also includes a waste removal function to eliminate defective capsules.

  • Q: Does the capsule polishing machine include the price of the vacuum cleaner? Do customers still need to bring their own vacuum cleaner?

    A:It includes a vacuum cleaner. It's just plastic, the kind used for household purposes. If the customer runs continuously for more than 6 hours, it is recommended to buy an industrial vacuum cleaner.

  • Q: Is there a vertical polishing machine?

    A:Yes, the price is higher than the horizontal one

  • Q: Is the sorting function and waste removal function of the capsule polishing machine the same?

    A:Same, remove empty capsules

×
